VCCM600S
The VCCM600S conduction cooled configurable power supply delivers a silent 600 Watts and up to 750 Watts of peak power for 5 seconds in a rugged 4” x 7” package and is the ultimate power solution for applications where reliability or audible noise are of concern.
VCCM600S
- World’s first conduction cooled modular power supply
- 600 Watts conduction cooled rating
- 750 Watts peak rating (5 seconds)
- 500 Watts convection rating
- Standby power ≤ 1Watts (in primary inhibit mode)
- Efficiency up to 92%
- Unique module design (100% SMT)
- Up to 4 isolated outputs at 150 Watts per channel
- Wide output adjust range
- Voltage and current dynamically controllable
- 5V/1A bias supply
- Mil-Std 810G compliant
- Semi F47 compliant
- Programmable start-up state (laser applications)
- 5 year warranty
- Approved to latest standards:
- Industrial (IEC/UL60950 2ND Edition),
- Medical (IEC/UL60601-1-2 3RD Edition),
- EMC (IEC/UL60601-1-2 4TH Edition)
| AC input voltage | 85 – 264 Vrms |
| Size | 4 x 7 x 1.61 Inches |
| Power rating | 600 Watts conduction 750 Watts peak 500 Watts convection |
| Efficiency | Up to 92% |
| Power factor | 0.99 |
| Holdup | 20mS |
| Standby power | ≤ 1 Watts |
| Baseplate operating temperature Range | -40°C To 85°C |
| Ambient operating temperature | -40°C To 70°C (Derating above 50°C) |
| Input leakage current | <1500uA |
| Output Options | |
| OPA | 1.5V-7.5V,25A, 125W |
| OPB | 4.5V-15V, 15A, 150W |
| OPC | 9V-30V, 7.5A, 150W |
| OPD | 18V-58V, 3.75A, 150W |
